Steel Control Box/Electric Enclosure
Steel Electrical Control Panel Enclosure
Product Description:
Material:Cold rolled sheet steel (METAL)
Surface finish: epoxy thermosetting powder coating,textured finished.
Thickness:
Body: 1.2mm, Door : 1.2mm, Galvanized mounting plate: 1.5mm, if the enclosures are smaller than 800X600mm.
Body: 1.5mm, Door : 1.5mm, Galvanized mounting plate: 2mm, if the enclosures are bigger than 800X600mm.
Supply include:
Body enclosure, door with foam PU sealing gasket, gland plate,galvanized mounting plate, sealing gasket and other fixing accessories.
Color: RAL7032 , RAL7035, or according the customer's request.
Protection degree:IP66
Selection Table
Model | Size(mm) | Model | Size(mm) |
| PT2 215 | 200X200X150 | PT6 425 | 600X400X250 |
| PT3 215 | 300X200X150 | PT7 525 | 700X500X250 |
| PT3 315 | 300X300X150 | PT8 625 | 800X600X250 |
| PT4 315 | 400X300X150 | PT9 625 | 900X600X250 |
| PT5 415 | 500X400X150 | PT10 825 | 1000X800X250 |
| PT6 415 | 600X400X150 | PT10 1025 | 1000X1000X250 |
| PT6 515 | 600X500X150 | PT12 825 | 1200X800X250 |
| PT7 515 | 700X500X150 | PT12 1225 | 1200X1200X250 |
| PT8 615 | 800X600X150 | PT14 1025 | 1400X1000X250 |
| PT3 2520 | 300X250X200 | PT4 330 | 400X300X300 |
| PT3 320 | 300X300X200 | PT5 530 | 500X500X300 |
| PT4 420 | 400X400X200 | PT6 430 | 600X400X300 |
| PT5 520 | 500X500X200 | PT7 630 | 700X600X300 |
| PT6 620 | 600X600X200 | PT8 630 | 800X600X300 |
| PT7 620 | 700X600X200 | PT9 630 | 900X600X300 |
| PT8 620 | 800X600X200 | PT12 1030 | 1200X1000X300 |
| PT8 820 | 800X800X200 | PT4 440 | 400X400X400 |
| PT8 820 | 800X800X200 | PT5 540 | 500X500X400 |
| PT10 1020 | 1000X1000X200 | PT6 440 | 600X400X400 |
| PT12 1020 | 1200X1000X200 | PT6 540 | 600X500X400 |
| PT3 2525 | 300X250X250 | PT7 640 | 700X600X400 |
| PT4 325 | 400X300X250 | PT8 640 | 800X600X400 |
| PT5 325 | 500X300X250 | PT10 840 | 1000X800X400 |
| PT5 425 | 500X400X250 | PT10 1040 | 1000X1000X400 |
******Other sizes avaliable on request .Cut-outs and drilled holes to your specifications. Should you have any questions or problems, please contact with us.*****
